Jenkinsfile - How to Create UI Form Text fields, Drop-down and Run for Different Conditions

October 07, 2022

Introduction
Jenkinsfile for UI and Run Automation

Introduction

I had to write a CICD system for one of our project. I had to deploy artifacts on different environments. We did not want it to be fully automated. This deployment job should be manually run, when we are fully sure.

The job should provide user the option of:

Which Environment (Dev/Stage/Prod)
Which Artifact to deploy
What is the version of artifact

Jenkinsfile for UI and Run Automation

Here is the complete Jenkinsfile.

pipeline {
    agent {
        node {
            label "MyNode"
        }
    }
    stages {
        stage('Take User Input') {
            steps {
                script {
                    properties([
                        parameters([
                            choice(
                                choices: ['Dev', 'Stage', 'Prod'],
                                name: 'DeployEnv',
                                description: "Select the environment"
                            ),
                            choice(
                                choices: ['ws-1', 'ws-1', 'worker-1'],
                                name: 'ArtifactId',
                                description: "Which artifact",
                            ),
                            string(
                                defaultValue: 'version of build',
                                name: 'Version',
                                description: "Write the version of build",
                                trim: true
                            )
                        ])
                    ])
                }
            }
        }
        stage('Run deployer') {
            steps {
                echo 'Deploying Artifacts to Kubernetes Env...'

                withCredentials([
                    [$class: 'UsernamePasswordMultiBinding',
                    credentialsId:"MY_CRED_ID",
                        usernameVariable: 'AZURE_SERVICE_USERNAME',
                        passwordVariable: 'AZURE_SERVICE_SECRET'],
                    [$class: 'UsernamePasswordMultiBinding', credentialsId:"MY_API_KEY",
                        usernameVariable: 'ARTIFACTORY_USERNAME',
                        passwordVariable: 'ARTIFACTORY_PASSWORD']
                ]) {
                    sh """
                        # installing kubectl
                        sudo curl -LO "https://dl.k8s.io/release/v1.25.2/bin/linux/amd64/kubectl"
                        sudo install -o root -g root -m 0755 kubectl /usr/local/bin/kubectl
                        kubectl version --client

                        echo "deploy to env=${params.DeployEnv}, artifact=${params.ArtifactId}, version=${params.Version}"

                        echo "Preparing runtime env..."
                        python3.8 -m pip install virtualenv
                        python3.8 -m venv python_env
                        source python_env/bin/activate
                        python3.8 -m pip install --upgrade pip
                        python3.8 -m pip install -r requirements.txt -i https://${ARTIFACTORY_USERNAME}:${ARTIFACTORY_PASSWORD}@artifactory.myorg.com/artifactory/api/pypi/pypi-myorg-release/simple

                        echo "Ready to run deployment..."
                        python3.8 deploy.py "${params.DeployEnv}" "${params.ArtifactId}" "${params.Version}"

                        deactivate
                    """
                }
            }
        }
    }
}

Lets break down the file in following parts:

Taking User Input from UI WIdgets

Jenkins provides option to render few UI widgets and taking their values. In my case, the values are static. But, you can take dynamic values too.

For example, a drop down is rendered by:

choice(
    choices: ['Dev', 'Stage', 'Prod'],
    name: 'DeployEnv',
    description: "Select the environment"
)

Accessing selected UI widget values

Whatever user selects, its value will be stored in variable name mentioned in name attribute. To access above mentioned value, I will use ${params.DeployEnv} in shell script step.

Example, this is how I’m using it:

echo "deploy to env=${params.DeployEnv}, artifact=${params.ArtifactId}, version=${params.Version}"

Fetching Multiple Credentials

You can store as many credentials in Jenkins, and I’ve fetched two credentials at the same time by:

withCredentials([
        [$class: 'UsernamePasswordMultiBinding',
        credentialsId:"MY_CRED_ID",
            usernameVariable: 'AZURE_SERVICE_USERNAME',
            passwordVariable: 'AZURE_SERVICE_SECRET'],
        [$class: 'UsernamePasswordMultiBinding', credentialsId:"MY_API_KEY",
            usernameVariable: 'ARTIFACTORY_USERNAME',
            passwordVariable: 'ARTIFACTORY_PASSWORD']
    ]) {
        ...
}

For example, MY_CRED_ID is the key stored in Jenkins, and I’m exposing its username and password in environment variables: AZURE_SERVICE_USERNAME, AZURE_SERVICE_SECRET

And finally, I’m running a python code, which has the automation to deploy files on kubernetes.

And again, if you do not want to run this job on every code commit, i.e. you want this job to run manually only. See How not to run Jenkin job on Code-commit
